Product Name：LED Curing Light
Description：
◆ Three solidification working modes:
Ø Mode 1: full mode-output with entire power in the whole the process.
Ø Mode 2: R: Ramp-up mode-output rises gradually from 30% to 100% in the one third treatment, and then lasts in full power in the other two third treatment.
Ø Mode 3: Pulse mode. Output with zero-power and entire power by turns every half seconds.
◆ Dormant function:
Ø If the product is not working over 30s, it can automatically turn into the inactive state to save battery. During the dormant state, the product's liquid crystal display will turn off automatically. Press any key on the panel can bring the function back to normal working situation.
◆ Automatic memory function:
Ø The product will automatically memorize the latest used working mode and time, no matter whether it is after the dormant state or charging state.
◆ Sound alert:
Ø There will be sound alerts if you choose working modes、start、curing process(every 5s) or end the process.
◆ The low power alert:
Ø The alert appears as a low-frequency sound” BEE". And if the battery's voltage is down and needs recharge, the sound alert should be two high-frequency sounds "BEE". At the same time, the LCD will show the electricity icon, When it reminds about low-voltage that means the curing light's power can't be assured. In this case, you can extend the irradiate time to assure the curing effect. When the battery is low than a quarter of the battery capacity, the battery icon will bicker, and the machine will stop the working, but the LCD still show natural。
◆ Conduct direction:
◆ 1 in the dormant state, press any key on the panel to turn into the stand-by state;
◆ 2 ON/OFF KEY: Presses the ON/OFF KEY first time, it goes in stand-by state. Press it again; it works in the latest used mode. During the operation, press this key to cancel the curing mode and change back to the stand-by state.
◆ 3 MODE KEY: The corresponding Mode will show in the LCD，press this key 3s,the system will turn into white mode. The icon “whiten” bicker, and the unit of the working seconds change to minute.
◆ Time Adjust Press: Press the key-press, the cure time will add one more second, the longest adjust is 40s, it will back to zero when it’s larger then 40s, the LCD will show the adjust time.
◆ Press the key-press for a long time, it can adjust the output of the light intensity，the light intensity icon will show with 5 case, every case stand-by 20%, the user could adjust the necessary light intensity base on the practical status。
Whiten use operation
◆ When you select the whiten model,the word “white” in the display flicker, that means the machine in the whiten model , “M” means the time unit is “Minute”,then press the time control key , it will add 1 more minute each one time , the Max should be 30m . Dentist should close the treating time depend on the sufferer’s status , connect the whiten tip and arm at the tooth which had apply whitening agent,press the “Start”,then it will show the blue light and then into the treating work , you can turn off this machine during the treatment 10 minutes per time once a day for a treatment . the whitening treatment can remove the surface and deep stains of teeth within 1-3 treatment.
Technical parameters
* Unit
Output power:…………………5 W
Size: ................................. Diameter 23×
Weight: .................................. 250g
Working voltage: ........................... 100-240V A C, 50-60HZ
*
Battery
Type: ................................. Lithium Ion
Battery capacity: ................................. 2200mAh
* optical parameters
LED Wave length: ................................. 420-480nm
Whitening head wave lenght :...................460-490nm
LED Luminous intensity: .................................800-- 1800mW/cm ²
Whitening head Luminous intensity:...................10000mW/cm ²
Times :............................................................1-30s4
